Service Call Tables
D014/D015/D078/D079 4-36 SM
Tray 1 feed error
SC503 B
The lift sensor is not activated
within 10 seconds after the tray lift
motor starts lifting the bottom
plate.
When the tray lowers, the tray lift
sensor does not go off within 1.5
sec.
 Tray lift motor defective or
disconnected
 Paper or other obstacle trapped
between tray and motor
 Pick-up solenoid disconnected
or blocked by an obstacle
Tray 2 feed error
SC504 B
The lift sensor is not activated
within 10 seconds after the tray lift
motor starts lifting the bottom
plate.
When the tray lowers, the tray lift
sensor does not go off within 1.5
sec.
 Tray lift motor defective or
disconnected
 Paper or other obstacle trapped
between tray and motor
 Pick-up solenoid disconnected
or blocked by an obstacle
Tandem tray rear fence motor error
SC505 C
The return sensor does not
switch on within 10 sec. after
the rear fence motor switches
on.
The HP sensor does not
switch on 10 sec. after the
rear fence motor switches on.
The HP sensor and return
sensor switch on at the same
time.
 Rear fence motor defective or poor
connection
 Paper or other obstacle interfering
with operation of the sensors
 Paper or other obstacle trapped
between tray and motor
 Motor mechanical overload due to
obstruction
 Return sensor or HP sensor
defective or dirty
