Service Call Tables
D014/D015/D078/D079 4-46 SM
Heating roller fusing lamp on error
SC565 A
After fusing belt reached
warm-up temperature, the
heating roller fusing lamp
remained on for 20 sec. while
the hot roller was not rotating.
 Do SP5810 to cancel the SC fusing
code.
 Thermistor damaged, or out of
position
 Fusing lamp disconnected, broken
Heating Roller Non-Contact Thermistor 3
SC566 A
Thermistor detects a
temperature less than 0
degrees more than 3
times.

Do SP5810 to cancel the SC fusing
code.

Hot Roller Thermistor ( SM 6.10.2,
Call Out #1) is disconnected, broken.
Pressure roller lift error 1
SC568 D
Even after the leading
edge of the paper
reached the fusing exit
sensor, the pressure
roller lift motor did not
raise the pressure roller.
 Pressure roller lift sensor connection
loose, broken, damaged
 Clean the pressure roller lift sensor
 Pressure roller lift harness loose, broken,
damage
 Pressure roller lift motor blocked by an
obstruction
 Pressure roller lift motor defective
Pressure roller lift error 2
SC569 B
Pressure roller lift motor
not operating correctly.
(No signal to indicate
completion of
operation.)
 Pressure roller lift sensor connection
loose, broken, damaged
 Clean the pressure roller lift sensor
 Pressure roller lift harness loose, broken,
damage
 Pressure roller lift motor blocked by an
obstruction
 Pressure roller lift motor defective
⇒
