Group 1000
D014/D015/D078/D079 5-2 SM
5.2 GROUP 1000
1001 Lead Edge Reg
Adjusts the printing leading edge registration using the trimming area pattern
(SP2109-2, Pattern No. 10).
[–9 to +9/ 0.1 mm]
Specification: 3 ±2mm
1002 Fine Adj LEdge (Thick)
Fine adjusts leading edge registration for thick paper (Thick 2, Thick 3).
[–9 to +9/ 0.1 mm]
1 Thick 2 Thick 2: 164 to 249.9 g/m
2
2 Thick 3 Thick 3: 250 to 300 g/m
2
1003 Side-to-Side Reg
Side-to-Side Registration Adjustment. Adjusts printing side-to-side registration for
each feed station, using the test pattern (SP2109-2, Pattern No. 10). These SP's
should be adjusted after replacing the laser synchronization detector or the laser
optical unit.
1 Tray 1 [–9 to +9/ 0.1 mm]
2 Tray 2
3 Tray 3
4 Tray 4
Japan Only
5 Bypass Tray
6 Dupx Tray
7 LCT LCT1: B473
8 WIDE LCT LCT2: D350
