Group 1000
SM 5-11 D014/D015/D078/D079
Service
Tables
53 Press Roll:2-S:Trace
54 Press Roll:2-S:Mid Thk
55 Press Roll:2-S:Thk1
56 Hot Roll:Wait:Norm
57 Hot Roll:Wait:Low
58 Hot Roll:Wait:High
59 Hot Roll L3:Ctr Corr Temp
60 Hot Roll L3:End correction Temp
61 Hot Roll:High Rot Temp
1106 Temp Ctrl
These SP codes control the temperature control of the hot roller and display the
temperatures of the hot roller, pressure roller, heating roller, and heating roller
lamps.
1 0:ON/OFF 1:PID
Hot roller fusing lamp control switch
0: OFF, 1: PID
2 Htg Roll Ctr Temp
Displays the temperature in centigrade of the fusing
lamp (center) in the heating roller. Range: 0 to 230
3 Htg Roll End Temp
Displays the temperature in centigrade of the fusing
lamp (ends) in the heating roller. Range: 0 to 230
4 Press Roll Temp
Displays the temperature in centigrade of the
pressure roller. Range: 0 to 230
5 Hot Roll Temp
Displays the temperature in centigrade of the hot
roller. Range: 0 to 230
