Group 2000
SM 5-23 D014/D015/D078/D079
Service
Tables
5.3 GROUP 2000
2101 Reg Col Interval Color Interval Registration Adjustment.
Use these SPs to correct problems with color registration. Color registration
problems can be detected by checking the results of 2901 002 Pattern 1. Before
doing these adjustments, try to solve the problem by doing SP2111. For more,
see "4. Troubleshooting" in the B132/B200 Service Manual.
1 Main Scan Dot:K
2 Main Scan Dot:M
3 Main Scan Dot:C
4 Main Scan Dot:Y
5 Main/Sub Scan:K
6 Main/Sub Scan:M
7 Main/Sub Scan:C
8 Main/Sub Scan:Y
9 Main/Sub Scan:K1-2
10 Main/Sub Scan:M1-2
11 Main/Sub Scan:C1-2
12 Main/Sub Scan:Y1-2
20 SubScan Line:K-M
21 SubScan Line:K-C
22 SubScan Line:K-Y
23 SubScan M Adj:K-M
34 SubScan M Adj:K-C
