Group 2000
D014/D015/D078/D079 5-32 SM
2112 Mag Point Adj
Magnification Point Adjustment. Corrects the difference in magnification for each
color in the left and right direction.
[-4 to +4/0/1]
Do SP2109 002 and print Pattern 1 on A3 size paper. Examine the pattern with a
scaled loupe. For every 50 μm adjust the setting in the left or right direction. A 1
step correction corrects 50 μm. For more, see "4. Troubleshooting" in the
B132/B200 Service Manual.
1 M Left
2 M Right
3 C Left
4 C Right
5 Y Left
6 Y Right
2150
Prt Area Pulse DFU
Pulse Setting: Print Area Only. These SPs fine adjust magnification in the
main scan direction in increments of 1/32 dots.
1-10 K Area 1 to 10 [-120 to +120/32 sub dot]
11-20 M Area 1 to 10
21 - 30 C Area 1 to 10
31 - 40 Y Area 1 to 10
