Group 2000
D014/D015/D078/D079 5-40 SM
2180 MUSIC Monitor
Displays the current and previous lens temperature readings.
1 Lens Temp
10 Previous Temp
2181 Alignment Result
These SPs display the amount of shift correction for each color, the amount of
correction done at each sensor in both the main scan and sub scan direction.
[0 to 9 999 999]
1 General
2 M Skew Amt
3 C Skew Amt
4 Y Skew Amt
10 M Main Skew 1
11 M Main Skew 2
12 M Main Skew 3
13 C Main Skew 1
14 C Main Skew 2
15 C Main Skew 3
16 Y Main Skew 1
17 Y Main Skew 2
18 Y Main Skew 3
20 M Sub Skew 1
