Group 2000
D014/D015/D078/D079 5-44 SM
62 Y Area 1
63 Y Area 2
64 Y Area 3
65 Y Area 4
66 Y Area 5
67 Y Area 6
68 Y Area 7
69 Y Area 8
70 Y Area 9
71 Y Area 10
72 Y Area 11
2201 Set DC Charge
These SPs set the dc bias for the standard speed and low speed mode, but take
effect only when SP3501 001 is set to "1" (Fixed). The dc bias (an absolute value)
is set to +200, making the default values for each color –700. The dc bias is
normally adjusted by the process control self-check, but when automatic process
control is switched off (by setting SP3501 001 to "1"), these values are used for the
charge potential.
1 K [-999 to –200/1V]
2 M [-999 to –200/1V]
3 C [-999 to –200/1V]
4 Y [-999 to –200/1V]
