Group 2000
SM 5-79 D014/D015/D078/D079
Service
Tables
SP2795 – More than SP2304 005 Threshold 5
These settings apply only to the image area printed on Special Paper 1 in
full-color mode.
1 ITB
7 Side1:PTR
8 Side1:SepDC
9 Side1:SepAC
12 Side2:PTR
13 Side2:SepDC
14 Side2:SepAC
[10 to 200/ 1%]
2801 Sp2 K Bias Set Bias for Special Paper 2: K
These SPs set the standard values of the electrical charges that are applied to 1)
create bias for image transfer from drum to ITB, 2) create bias for image transfer
from ITB to paper (PTR), and 3) neutralize the charges on the both sides of the
paper to separate the paper from the ITB (SepDC, SepAC). These settings are
used when printing on Special Paper 2 in the black-and-white mode and are
applied only to the image area.
1 ITB
[0 to 70/0.1 μa]
7 Side1:PTR
[-100 to 0/1 μa]
8 Side1:SepDC
[0 to 10/0.1 μa]
9 Side1:SepAC [8 to 12/0.1 kV]
12 Side2:PTR
[-100 to 0/1 μa]
13 Side2:SepDC
[0 to 10/0.1 μa]
14 Side2:SepAC [8 to 12/0.1 kV]
