Group 5000
SM 5-205 D014/D015/D078/D079
Service
Tables
"2001:1234:5678:9012:abcd:ef01:2345:6789": prefixlen 64
However, the actual IPV6 address display is abbreviated according to the following rules.
Rules for Abbreviating IPV6 Addresses
The IPV6 address is expressed in hexadecimal delimited by colons (:) with the following
characters:
0123456789abcdefABCDEF
1. A colon is inserted as a delimiter every 4th hexadecimal character.
fe80:0000:0000:0000:0207:40ff:0000:340e
2. The notations can be abbreviated by eliminating zeros where the MSB and digits
following the MSB are zero. The example in "2" above, then, becomes
fe80:0:0:0207:40ff:0:340e
3. Sections where only zeros exist can be abbreviated with double colons (::). This
abbreviation can be done also where succeeding sections contain only zeros (but
this can be done only at one point in the address). The example in "2" and "3" above
then becomes:
fe80::207:40ff:0:340e (only the first null sets zero digits are abbreviated as "::")
-or-
fe80:0:0:0:207:40ff::340e (only the last null set before "340e" is abbreviated as "::")
161
IPv6 Stateless Auto
Setting
Enable or disables the automatic setting for IPv6
stateless.
Web Item visible
236
Displays or does not display the Web system items.
[0 x 0000 to 0 x ffff / 0 x ffff] 0: Not displayed, 1: Displayed
bit0: Net RICOH
bit1: Consumable Supplier
bit2-15: Reserved (all)
Web shopping link visible
237
Displays or does not display the link to Net RICOH on the top page and link
page of the web system.
[0 to 1 / 1 / 1]
0: Not display, 1:Display
