Group 6000
SM 5-253 D014/D015/D078/D079
Service
Tables
37 Fold Exit Sn
38 Book Full Sn 1
39 Book Full Sn 2
40 BStapler 1 Op
41 BStapler 1 In
42 BStaples 1 In
43 BStapler 2 Op
44 BStapler 2 In
45 BStaples 2 In
46 Up TrayFull:3000
47 Out Jog HP Sn 1
48 Out Jog HP Sn 2
49 OutJog RetractSn
6116 Output Check:Fin1 2000/3000-Sheet Finishers D373/D374
Use these SP codes to perform the output checks for either the 2000-Sheet
Finisher D373 or 3000-Sheet Finisher D374.
The following abbreviations are used below:
 M: Motor
 JG: Junction Gate
 SOL: Solenoid
 Stp: Staple
 Bot: Bottom
1 Entrance M
2 Up Trans M
3 Low Trans M
4 Exit M
Rev. 08/2008
