Ricoh D014 - Page 797

Group 6000
SM 5-255 D014/D015/D078/D079
Service
Tables
28 Punch Move M
29 Punch Reg M
30 OutJog M:Front
31 OutJog M:Rear
32 OutJog Retract M
6150 Fine Adj Staple:Fin2 3000-Sheet Finisher B830
This SP corrects the distance between the jogger fences and the sides of the
stack on the finisher stapling tray.
1 A3 SEF
2 B4 SEF
3 A4 SEF
4 A4 LEF
5 B5 SEF
6 B5 LEF
7 DLT SEF
8 LG SEF
9 LT SEF
10 LT LEF
11 Custom
[-15~+1.5/-2/0.5 mm]
 + Value: ncreases distance between jogger fences
and the sides of the stack.
 - Value: Decreases the distance between the
jogger fences and the sides of the stack.
6151 Adj Staple Pos:Fin2 3000-Sheet Finisher B830
This SP corrects the stapling position of the corner stapler.
1 A3 SEF [-2~+2/0/0.5 mm]
Rev. 08/2008
