Group 6000
D014/D015/D078/D079 5-260 SM
37 Shift Jog HP Sn
38 OutJog RetractSn
39 Emergency Stop SW
40 Top Fence HP Sensor
41 Bottom Fence HP Sensor
42 Shift Tray Full Sn:Z-Fold
43 Shift Tray Exit Sensor 2
44 Upper Tray JG HP Sensor
45 Stapler JG HP Sensor
46 Prestack JG HP Sensor
47 Stop Prestack Sensor
48 Prestack Stopper HP Sensor
49 Shift Tray HP Sensor 2
50 Staple Trim Hopper Set Sn
6157 Output Check:Fin2 3000-Sheet Finisher B830
Use these SP codes to perform the output checks for either the 3000-Sheet
Finisher B830. The following abbreviations are used below:
Mtr: Motor
M: Motor
JG: Junction Gate
SOL: Solenoid
Stp: Staple
Bot: Bottom
1 Upper Transport Motor
2 Shift Exit M:Cont
3 Upper Tray JG Mtr:Cont
Rev. 08/2008
To Next Page
