Group 6000
D014/D015/D078/D079 5-262 SM
27 Lower Transport Mtr:Cont
28 Upper Tray Exit Mtr:Cont
29 Positioning Roller Mtr:Cont
30 Prestack Trans Mtr:Cont
31 Staple Trim Chute SOL:1 Op
6250 Input Check:Fin3
For future use. (Oct. 2007)
6251 Output Check:Fin3
For future use. (Oct. 2007)
6301 Fine Adj 1st, 2nd Z-Fold
Use these SP codes to adjust the positions of the Z-folds done with the Z-Fold
Unit B660. The 1st and 2nd folds can be adjusted separately.
Rev. 08/2008
