Group 6000
D014/D015/D078/D079 5-270 SM
6506 Adj Jog:Binding 1
For future use. (Oct. 2007)
6508 Input Check:Fin4
For future use. (Oct. 2007)
6509 Output Check:Fin4
For future use. (Oct. 2007)
6800 Sheet Conversion (Thick Paper)
Permits punching, including tab sheets.
Note: Do not change this setting.
[1 to 3/3/1 sheet]
1: 1 Sheet
2: 2 Sheets
3: 3 Sheets
6890 Punch Function Enabled (Z-Fold)
Switch Z-folding off and on. Default: 0 (Off)
0:No 1:Yes
6900 ADF Bottom Lift
This SP setting determines whether the bottom plate lift motor of the of the
ARDF switches on:
When the original is set in the ARDF original tray
-or-
When the [Start] key is pressed.
The ARDF bottom plate lift motor raises the bottom plate that pushes up the
original tray and raises it to the optimum feed position.
[0~1/1]
0: Bottom plate lifts immediately after originals are set (Default)
1: Bottom plate does not lift until [Start] key is pushed.
Rev. 08/2008
