D014/D015/D078/D079 5-272 SM
7504 Paper Jam Loc D014/D015/D078/D079 Copier
Displays the list of possible locations where a jam could have occurred in the
copier. Press the appropriate key to display the jam count for that location.
These jams are caused by the failure of a sensor to activate.
Operation Panel Actual Component Name
1 At Power On
3 Tray 1: No Feed
SP7504-003 indicates the jam counter occurred
at the Tray 1.
4 NA
SP7504-004 is not used on D014/D015/D078
/D079 copier and the value is always “0”.
5 Tray 2: No Feed
SP7504-005 indicates the jam counter occurred
at the Tray 2.
6 Tray 3: No Feed
SP7504-006 indicates the jam counter occurred
at the Tray 3.
7 LCT: No Feed
8 Trans 1 Sn:Late 1st Vertical Transport Sensor
9 Trans 2 Sn:Late 2nd Vertical Transport Sensor
10 Trans 3 Sn:Late 3rd Vertical Transport Sensor
11 Trans 4 Sn:Late 4th Vertical Transport Sensor
12 Relay Sn: Late Relay Sensor
13 Reg Sn:Late Registration Sensor
14 Fusing Ex Sn:Late Fusing Exit Sensor
16 Main Ex Sn:Late Paper Exit Sensor
19 Dup Ent Sn:Late Duplex Entrance Sensor
20 Dup Trans Sn1:Late Duplex Transport Sensor 1
21 Dup Trans Sn2:Late Duplex Transport Sensor 2
22 Dup Trans Sn3:Late Duplex Transport Sensor 3
⇒
⇒
⇒
⇒
