Group 7000
SM 5-285 D014/D015/D078/D079
Service
Tables
7623 Standard Value
7624 Operational Value
1 K PCU#
2 K PCU Cleaning Blade
3 K PCU Lube Bar
4 K PCU Lube App/Clng Blade
5 K PCU Developer
6 K PCU Drum
7 K PCU Charge Grid Unit
8 K PCU Charge Grid Wire
9 K PCU Idle Gear
10 K PCU Lube App/Clng Brush
11 K PCU Toner Cleaning Brush
Not Used
12 K PCU Joint
13 M PCU#
14 M PCU Cleaning Blade
15 M PCU Lube Bar
16 M PCU Lube App/Clng Blade
17 M PCU Developer
18 M PCU Drum
19 M PCU Charge Roller Unit
20 M PCU Idle Gear
21 M PCU Lube App/Clng Brush
To Next Page
