Ricoh D014 - Page 888

Group 8000
D014/D015/D078/D079 5-346 SM
8696 L:TX PGS/LS
button from within the Copy mode screen go to the C:
counter.
Notes
 Print jobs done with Web Image Monitor and Desk Top Binder are added to the count.
 If several documents are merged for sending, the number of pages stored are counted
for the application that stored them
 When several documents are sent by a Fax broadcast, the F: count is done for the
number of pages sent to each destination.
TX PGS/Port [0~9999999/ 1]
8701
These SPs count the number of pages sent by the physical port used to
send them. For example, if a 3-page original is sent to 4 destinations via
ISDN G4, the count for ISDN (G3, G4) is 12.
1 PSTN-1
2 PSTN-2
3 PSTN-3
4 ISDN (G3,G4)
5 Network
T:Scan PGS/Comp [0~9999999/ 1]
8711
These SPs count the number of compressed pages scanned into the
document server, counted by the formats slisted below.
1 JPEG/JPEG2000
2 TIFF (Multi/Single)
3 PDF
4 Other
