Network structures
6.1 WLAN
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
156 Configuration Manual, 10/2015, C79000-G8976-C351-05
Requirement
● The "Allowed channels only" function is enabled.
You are in the Interface Configuration mode of the WLAN interface.
The command prompt is as follows:
cli (config-if-wlan-0-X)#
Syntax
Call up the command with the following parameters:
wlan allowed channels{ all | none | {[add][del]} [ 2.4 | 4 | 5 ] <channels> }
The parameters have the following meaning:
Parameters
Description
all
All permitted channels are entered in the list.
none
• Access point:
All channels except for the following channels are deleted:
– Operative channel
– Alternative DFS channel
If "Auto" is set for the channel, the list is deleted and the first valid
channel of the selected frequency band is applied.
• Client:
The list is deleted and the first valid channel of the selected frequency
band is applied.
add
The channels located in the <channel> parameter are added to the list.
del
The channels located in the <channel> parameter are deleted from the
list.
2.4
Optional parameter. Use this parameter to specify the frequency band
from which you want to add one or more channels to the list.
4
Optional parameter. Use this parameter to specify the frequency band
from which you want to add one or more channels to the list.
5
Optional parameter. Use this parameter to specify the frequency band
from which you want to add one or more channels to the list.
channels
Number of permitted channels.
To specify in more than one channel, write the channel numbers in quotes
and use the <space> as the delimiter.
Example:
wlan allowed channels list 5 "40 36"
If you do not use the "
add" parameter, the existing entries in the list are
overwritten.
Result
The list of permitted channels has been created.
