Network structures
6.3 Spanning Tree
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
266 Configuration Manual, 10/2015, C79000-G8976-C351-05
Parameter
Description
Range of values / note
link-type
Connection status of the following
network segment
•
point-to-point
•
shared
Default:
•
point-to-point
The connection is configured
as
full-duplex
•
shared
in all other cases
portfast
Enables the PortFast function -
Default: disabled
port-priority
Priority of the interface 0 ... 240 in steps of 16
Default: 128
Note
Configure multiple properties
With each call of the command, you can configure precisely one property.
If you want to configure several proper
ties, call the command several times.
Result
The selected property is configured.
Further notes
You can reset the setting to the default with the no spanning-tree (properties) command.
You display these settings and other information with the commands that start with
show
spanning tree ...
.
