Command reference
R&S
®
ZNB/ZNBT
1037User Manual 1173.9163.02 ─ 62
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding<ListId>:DEFine
<PP_First>,<PP_Second>,<PP_First>,...
Creates one or more port pairs for port set deembedding. The command can be used
repeatedly to extend or (partially) overwrite the list of port sets for deembedding.
See CALCulate<Ch>:TRANsform:VNETworks:PSET:DEEMbedding<ListId>:
DEFine on page 1046 for general port set definition.
Suffix:
<Ch>
.
Channel number
<ListId> Index of the defined port set within the channel's overall list of
port sets for deembedding.
Port sets for deembedding must be numbered consecutively, i.e.
port set <ListId> can only be created if port set <ListId>-1
already exists. If several port pairs are specified, <ListId> is the
number of the first port pair to be created.
Parameters:
<PP_First>,
<PP_Second>,
<PP_First>, ...
Sequence of port pairs, each one consisting of two different
ports.
The port pairs don't have to be disjoint.
Example: See CALCulate<Ch>:TRANsform:VNETworks:PPAir:
DEEMbedding<ListId>[:STATe]
Usage: Setting only
Manual operation: See "Add / Delete" on page 609
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding:DELete
Deletes all port sets (including port pairs) previously defined for deembedding.
Suffix:
<Ch>
.
Channel number
Example: See CALCulate<Ch>:TRANsform:VNETworks:PPAir:
DEEMbedding<ListId>[:STATe]
Usage: Event
Manual operation: See "Add / Delete" on page 609
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding<ListId>:
PARameters:C<1|2|3> <CircuitModel>, <Capacitance>
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding<ListId>:
PARameters:C<1|2|3>? <CircuitModel>
Specifies the capacitance value C<i> in the different lumped circuit models for port pair
deembedding.
In the query form, the <Capacitance> parameter must be omitted. The command
returns the capacitance value for the specified circuit model.
SCPI command reference
