‘PABS’
9-term correction factors, defined for the lowest source port
<SourcePort> for each SMARTerCal; <LoadPort> is ignored
'L1', 'L2'
9-term correction factors, defined between the source port
<SourcePort> and the load port <LoadPort>
Range: The error terms are dimensionless complex num-
bers.
*RST: n/a
<SourcePort> Source port number
<LoadPort> Load port number. If the error term is not related to the load port,
a dummy number can be used; e.g. CORR:CDAT
'REFLTRACK', 1, 0
<CorrectionData> Correction data set (one complex number per sweep point) to be
transferred to the analyzer either in ASCII or block data format,
depending on the current FORMat[:DATA] setting. The correc-
tion data set is assigned to the specified channel, error term,
source and load port.
This parameter must not be used for queries.
Example: See [SENSe<Ch>:]CORRection:COLLect:SAVE:
SELected:DEFault.
The different calibration types of the analyzer provide the following error terms:
Calibration type Parameters in
[SENSe<Ch>:]CORRection:
COLLect:METHod:DEFine
Available error terms (depending on port num-
bers)
One-port normalization (reflection)
using an open or a short standard
REFL, RSHort 'REFLTRACK'
Full one port ("Refl OSM") FOPort 'DIRECTIVITY', 'SRCMATCH', 'REFLTRACK'
Two-port normalization FRTRans 'TRANSTRACK'
One path two port OPTPort 'DIRECTIVITY', 'SRCMATCH', 'REFLTRACK',
'TRANSTRACK'
TOSM TOSM 'DIRECTIVITY', 'SRCMATCH', 'REFLTRACK',
'LOADMATCH', 'TRANSTRACK'
TOM, TSM, TRM, TRL, TNA TOM | TSM | TRM | TRL | TNA 'DIRECTIVITY', 'SRCMATCH', 'REFLTRACK',
'LOADMATCH', 'TRANSTRACK' (for reading and
writing)
'G11' ... 'G22' and 'H11', 'H12', 'H22' (for reading
only; the 'H21' matrix elements are normalized to
1)
[SENSe<Ch>:]CORRection:CONNection <ConnectorName>[, <Mode>[, <Gender>[,
<RelPermittivity>[, <RefImpedance>]]]]
Configures the user-defined connector types.
SCPI command reference
