R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1271User Manual 1173.9163.02 ─ 62
<SweepType> CW | FIXed | SWEep
SWEep - the full formula is applied. For frequency sweeps, the
command defines a sweep range.
CW | FIXed - the reduced formula with f
b
= 0 is applied; the com-
mand defines a fixed frequency.
*RST: SWEep
Example:
*RST; FREQ:STAR 1E+9; STOP 1.1E+9
Reset the analyzer (activating a frequency sweep) and set the
sweep range between 1 GHz and 1.1 GHz.
SYST:COMM:RDEV:PMET1:DEF 'USB Power Meter',
'NRP-Z55', 'usb', '100045'
Configure an R&S NRP power meter as external power meter
no. 1, assigning the name USB Power Meter and an serial num-
ber 100045.
SENS:FREQ:CONV:ARB:PMET 2, 1, 1E+9, SWE
Convert the receiver frequency to the range between 3 GHz and
3.2 GHz.
Manual operation: See "Frequency Conversion Formula" on page 566
[SENSe<Ch>:]FREQuency:CONVersion:GAIN:LMCorrection <Boolean>
Enables or disables load match correction for frequency transmission S-parameters
(conversion gain factors in case of frequency-converting measurements).
Suffix:
<Ch>
.
Channel number
Parameters:
<Boolean> *RST: ON
Example: See SOURce<Ch>:FREQuency<PhyPt>:CONVersion:
ARBitrary:IFRequency
Manual operation: See "Load Match Correction" on page 532
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:FIXed<Stg> <InputOutput>
Selects the mixer input or output signal which is at the fixed frequency defined via
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed.
Suffix:
<Ch>
.
Channel number.
<Stg> Counter for fixed signal (1 if only one mixer stage is used, 1 or 2
for 2 mixer stages).
