R&S ZNB Series User Manual

GUI reference
R&S
®
ZNB/ZNBT
460User Manual 1173.9163.02 ─ 62
Access: Calibration Unit wizard (MultiCal), Step 1: "Ports" > "Add..." / "Modify..."
●
The "Multiple Cal in Calibration Wizard" (MultiCal) feature is disabled by default
and has to be activated in the Calibration tab of the "System Config" dialog.
●
For background information on calibration types, see Chapter 4.5.1, "Calibration
types", on page 163.
The layout of the main panel depends on the number of test ports available.
Figure 5-18: Define Calibration dialog (MultiCal, > 4 test ports)
Figure 5-19: Define Calibration dialog (MultiCal, Inline Calibration System)
Cal softtool
