Getting started
R&S
®
ZNB/ZNBT
65User Manual 1173.9163.02 ─ 62
All dialogs are operated in a similar way.
●
To open a dialog, select a softtool button with three dots appearing in its label (e.g.
"Start... (Manual)").
●
The title bar of each dialog contains some convenience functions:
– Use the "Dialog Transparency" function to make the display elements behind
the dialog visible.
Note: The "Dialog Transparency" is a global setting, i.e. it applies to all dialogs.
–
Use the icon to create a screenshot of the dialog.
●
Drag and drop the lower right corner of the dialog to modify its size.
●
Some dialogs are subdivided into tabs, containing groups of related settings. Acti-
vate a tab to access those settings.
See also Chapter 4.2.2.1, "Immediate vs. confirmed settings", on page 114.
The Help system provides useful information about each dialog's specific settings.
Select "Help" to open the Help.
Operating the instrument
