Before executing this command, the pattern type must be set to USER (see
CALCulate<Chn>:EYE:INPut:BPATtern:TYPE).
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<BitLength> Stream length, specified with units BITS, KIBITS (2^10 BITS),
MIBITS (2^20 BITS), or GIBITS (2^30 BITS)
Default unit: BITS
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Length" on page 693
CALCulate<Chn>:EYE:INPut:LENGth:PRBS <PrbsLength>
Defines the length of the pseudo-random binary sequence to be simulated for the rela-
ted eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Before executing this command the pattern type must be set to PRBS (see
CALCulate<Chn>:EYE:INPut:BPATtern:TYPE).
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<PrbsLength> L5 | L7 | L9 | L10 | L11 | L13 | L15
Li represents an actual sequence length of 2
i
- 1.
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Length" on page 693
CALCulate<Chn>:EYE:INPut:MODulation <PAMType>
Defines or queries the modulation type of the signal to be simulated for the related eye
diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<PAMType> NRZ | PM4 | PM8 | PM16
NRZ, PAM-4, PAM-8 or PAM-16
*RST: NRZ
Manual operation: See "Modulation" on page 693
