Parameters:
<Boolean> *RST: OFF
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Encoder" on page 696
CALCulate<Chn>:EYE:STIMulus:LOWPass <Boolean>
Enables/disables a single pole low pass filter in the binary signal generator simulation
of the related eye diagram measurement.
The low-pass is defined using its rise time (see CALCulate<Chn>:EYE:INPut:
RTIMe:DATA on page 865) and rise time definition (see CALCulate<Chn>:EYE:
INPut:RTIMe:THReshold on page 865).
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Boolean> *RST: OFF
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Low Pass" on page 694
CALCulate<Chn>:EYE:STIMulus:SCRambler <Boolean>
Enables/disables the scrambler in the bit stream simulation of the related eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Boolean> *RST: OFF
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Scrambler" on page 696
CALCulate<Chn>:EYE:VIEW <EyeView>
Allows to shorten the calculation chain of the related eye diagram without deactivating
the building blocks at the tail end.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
SCPI command reference
