Specifications
D014/D015/D078/D079 7-32 SM
LAMPS
L1 Exposure Lamp Projects high intensity light on the original for exposure.
L2
Heating Roller Fusing
Lamp 3 (Center)
Heats only the center of the heating roller.
(NA, EU: 700W)
L3
Heating Roller Fusing
Lamp 2 (Ends)
Heats only the ends of the heating roller.
(NA, EU: 700W)
L4
Heating Roller Fusing
Lamp 1 (Main)
Heats the entire heating roller from end to end.
(NA D014/D078: 250W)
(NA D015/D079, EU: 400W)
L5
Pressure Roller
Fusing Lamp
Heats the pressure roller.
(NA, EU: 400W)
MOTORS
M1 Scanner Motor Drives the scanner unit
M2 Lower Relay Motor
Drives the lower relay roller of the relay unit at the
vertical transport section.
M3
Paper Feed Motor: Tray
1
Drives the paper feed roller and grip roller of tray 1
(tandem tray).
M4
Paper Feed Motor: Tray
3
Drives the paper feed roller and grip roller of tray 3
(bottom tray).
M5
Paper Feed Motor: Tray
2
Drives the paper feed roller and grip roller of tray 2
(middle tray).
M6
Waste Toner
Distribution Motor
Drives the coil that spans the top of the waste toner
bottle.
M7 Lift Motor - Tray 2
Switches on and drives a shaft and coupling that raises
a lift arm against the bottom plate under the paper stack
in tray 2
M8 Lift Motor: Tray 3
Drives a shaft and coupling that raises a lift arm against
the bottom plate under the paper stack in tray 3.
Rev. 04/2008
⇒
⇒
⇒
⇒
