Specifications
SM 7-33 D014/D015/D078/D079
Specifications
M9 Lift Motor: Tray 1
Drives pulleys and cables that lift the bottom plate of
tray 1 (tandem tray) until the top of the paper stack
reaches the correct height for feeding.
M10
Rear Fence Motor -
Tray 1
Switches on when the right paper tray sensor of the
tandem paper tray unit detects paper out and the left
paper tray sensor detects paper present.
M11 ITB Lift Motor Rotates the cam that raises and lowers the ITB belt.
M12 Ozone Fan Motor
Draws air from around the drums and through the
ozone filter.
M13
Fusing Fan Motor:
Lower
Cools the fusing unit.
M14
Fusing Cooling Fan
Motor
Draws cool air into the fusing unit through a vent and
past a heat sink mounted above the fusing unit.
M15
Fusing Exhaust Fan
Motor
Draws the hot air away from the heat sink mounted
above the fusing unit and expels the hot air through a
vent
M16 Fusing/Exit Motor Drives the fusing unit and paper exit.
M17 PTR Motor Drives the paper transfer roller (PTR).
M18 Bypass Feed Motor
Drives the upper relay roller that feeds each sheet to
the registration roller.
M19 Duplex Jogger Motor Moves the jogger fences in the duplex unit.
M20 Duplex Unit Fan Motor Cools the duplex unit.
M21 Duplex Transport Motor Drives transport rollers 3, 4 in the duplex unit.
M22 Duplex Inverter Motor Feeds paper to the jogger section.
M23 Registration Motor Rotates the registration roller.
Rev. 04/2008
⇒
