Specifications
D014/D015/D078/D079 7-34 SM
M24 Belt Cleaning Fan
Cools the upper area of the transfer unit where the
PCUs contact the ITB.
M25 Pipe Cooling Fan Motor
Pulls in air draws it over the fins attached to the front
end of the heat pipe roller.
M26
Paper Transport Fan
Motor - Rear
1 of 2 vacuum fans that produce suction to kepp paper
on the transport belt.
M27
Paper Transport Fan
Motor - Front
1 of 2 vacuum fans that produce suction to kepp paper
on the transport belt.
M28 Paper Exit Fan Motor
Draws hot air from around the paper exit area and
expels it from the left side of the machine.
M29 Front Duplex Fan Motor Draws hot air out of the duplex unit.
M30 Rear Duplex Fan Motor Draws hot air out of the duplex unit.
M31 Potential Sensor Fan
Circulates air around the potential sensors inside the
copier to keep them cool.
M32 Cooling Fan Motor
Draws air and sends it through a duct to the four PCU
cooling fans.
M33 Circulation Fan Motor Circulates air.
M34
Laser Unit Cooling Fan
Motor - Front
Draws cool air into the machine.
M35
Laser Unit Cooing Fan
Motor - Rear
Expels hot air from the machine on the left side.
M36 Development Motor: K Drives the Y development unit.
M37 Development Motor: C Drives the C development unit.
M38 Development Motor: M Drives the M development unit.
⇒
Rev. 04/2008
⇒
⇒
⇒
⇒
