Specifications
SM 7-35 D014/D015/D078/D079
Specifications
M39 Development Motor: K Drives the K development unit.
M40
Controller Box Exhaust
Fan Motor 2
1 of 2 fans that cool the printed circuit boards at the
back of the machine.
M41
Controller Box Exhaust
Fan Motor 1
1 of 2 fans that cool the printed circuit boards at the
back of the machine.
M42 Drum Motor: Y Drives the drum in the Yellow PCU.
M43 Drum Motor: C Drives the drum in the Cyan PCU.
M44 Drum Motor: M Drives the drum in the Magenta PCU.
M45 Drum Motor: K Drives the drum in the Black PCU.
M46 ITB Drive Motor Rotates the image transfer roller that drives the ITB.
M47 3rd Mirror Motor - M
Fine adjusts the position of the 3rd mirror of the optics
for M (magenta) during MUSIC adjustment.
M48 Polygon Mirror Motor Rotates the polygon mirror in the laser optics unit
M49 3rd Mirror Motor - Y
Fine adjusts the position of the 3rd mirror of the optics
for Y (Yellow) during MUSIC adjustment.
M50 3rd Mirror Motor - C
Fine adjusts the position of the 3rd mirror of the optics
for C (Cyan) during MUSIC adjustment.
M51 Toner Hopper Motor
Drives the toner pump clutch and sub hopper clutch of
each PCU.
M52 PCU Fan Motor: Y Cools the Yellow PCU.
M53 PCU Fan Motor: C Cools the Cyan PCU.
M54 PCU Fan Motor: M Cools the Magenta PCU
Rev. 04/2008
⇒
