Specifications
D014/D015/D078/D079 7-36 SM
M55
Scanner Unit Fan
Motor - Rear Left
Cools the left, rear corner of the SIOB.
M56
Scanner Unit Fan
Motor - Rear Center
Cools the rear, center area of the SIOB.
M57
Scanner Unit Fan
Motor - Right
Exhausts warm air from the SIOB area.
M58
Waste Toner Collection
Bottle Motor
Drives the waste toner bottle transport coil that moves
the toner from the central collection point into the waste
toner bottle.
M59 Development Intake
Fan – K
Cools the K development unit.
M60 Development Intake
Fan – M
Cools the M development unit.
M61 Development Intake
Fan – C
Cools the C development unit.
M62 Development Intake
Fan – Y
Cools the Y development unit.
M63 Drum Cleaning Motor
(Y)
Drives the Y drum cleaning rollers
M64 Drum Cleaning Motor
(C)
Drives the C drum cleaning rollers
M65 Drum Cleaning Motor
(M)
Drives the M drum cleaning rollers
M66 Drum Cleaning Motor
(K)
Drives the K drum cleaning rollers.
⇒
Rev. 04/2008
