D014/D015/D078/D079 7-38 SM
MECHANICAL CLUTCHES
MC1 Bypass Feed Clutch
Engages and operates the pick-up roller at the bypass
feed tray.
MC2 Toner Pump Clutch: M
Engages the and drives the Magenta toner pump to pull
toner from the Magenta STC.
MC3 Toner Supply Clutch: M
Engages the toner supply coils in the sub hopper of the
Magenta PCU to send toner to the development unit
below.
MC4 Toner Pump Clutch : K
Engages the and drives the Black toner pump to pull
toner from the Black STC.
MC5 Toner Supply Clutch : K
Engages the toner supply coils in the sub hopper of the
Black PCU to send toner to the development unit below.
MC6 Toner Pump Clutch: Y
Engages the drive shaft and rotor of the Yellow toner
pump to pull toner from the Yellow STC when more
toner is needed.
MC7 Toner Supply Clutch: Y
Engages the toner supply coils in the sub hopper of the
Yellow PCU to send toner to the development unit
below.
MC8 Toner Pump Clutch: C
Engages the and drives the Cyan toner pump to pull
toner from the Cyan STC.
MC9 Toner Supply Clutch: C
Engages the toner supply coils in the sub hopper of the
Cyan PCU to send toner to the development unit below.
Rev. 04/2008
