Specifications
SM 7-45 D014/D015/D078/D079
Specifications
S16
Waste Toner Bottle Set
Sensor
Detects the position of the waste toner bottle and
confirms whether it is set correctly.
S17
Waste Toner Bottle
Near-Full Sensor
When the level of the waste toner rises high
enough to move the actuator of this sensor out
of its normal position, the sensor signals the
machine that the waste toner bottle is nearly full.
S18
Waste Toner Bottle Full
Sensor
Signals an alert when the waste toner bottle is
full.
S19 Paper Feed Sensor - Tray 1
Detects the leading edge of each sheet of paper
from the pick–up roller of tray 1 (tandem tray)
and switches off the pick–up roller solenoid so
the pick–up roller lifts.
S20
Vertical Transport Sensor -
Tray 1
Detects the leading edge and trailing edge of
each sheet fed from tray 1, 2, and 3 and signals
a jam if the edges do not pass at the prescribed
time.
S21 Paper End Sensor - Tray 1 Detects when the last sheet is fed from tray 1.
S22 Lift Sensor - Tray 1
Detects when the pick–up roller (pushed up by
the top of the paper stack in the right side of the
tandem tray) has reached the correct height for
paper feed and then switches off the tray 1
(tandem tray) lift motor.
S23
Paper Near End Sensor -
Tray 2
Detects the near end condition for tray 2 (middle
tray, a universal cassette).
S24
Paper Near End Sensor:
Tray 3
Detects the near end condition for tray 3 (middle
tray, a universal cassette).
S25
Front Side Fence Open
Sensor
Detects the actuator on the front side fence after
it has reached the open position in the tandem
tray.
