Specifications
D014/D015/D078/D079 7-46 SM
S26
Front Side Fence Closed
Sensor
Detects the actuator on the front side fence after
it has reached the closed position in the tandem
tray.
S27
Rear Side Fence Open
Sensor
Detects the actuator on the rear side fence after
it has reached the open position in the tandem
tray.
S28
Rear Side Fence Closed
Sensor
Detects the actuator on the rear side fence after
it has reached the closed position in the tandem
tray.
S29 Right Tray Down Sensor
Detects the bottom plate of the right tray and
switches off the tray 1 lift motor and stops the
bottom plate.
S30
Paper Near End Sensor -
Tray 1
Signals 10% paper remaining when the actuator
on the right rail of the right tray in the tandem
tray passes.
S31 Paper Height Sensor
Signals 100% paper remaining until activated.
Signals 50% paper remaining when the actuator
on the left rail of the right tray in the tandem tray
passes.
S32 Paper Height Sensor
Signals 30% paper remaining when the actuator
on the left rail of the right tray in the tandem tray
passes.
S33 Paper Height Sensor
When near end sensor 1 on right rail of the right
tray of the tandem tray is actuated, and paper
height sensor 3 has detected the passing of the
actuator on the left rail, then the near end sensor
signals 10% paper remaining.
S34 Right Tray Paper Sensor
Detects paper in the right side of the tandem
paper tray.
Rev. 04/2008
