Specifications
SM 7-51 D014/D015/D078/D079
Specifications
S75 Original Length Sensors - 1
APS2 (a board) holds two original length
sensors under the exposure glass. The detection
combinations of these sensors determine the
length of the original on the exposure glass
positioned for SEF.
S76 Original Length Sensor -2
APS3 (a board) holds one original length sensor
under the exposure glass. The detection
combination of this sensor and other sensors
determine the length of the original on the
exposure glass positioned for SEF.
S77 Accordion Jam Sensor
Detects jams at the fusing exit by confirming that
paper arrives at the prescribed time.
S78 Fusing Exit Sensor
Detects jams at the fusing exit by confirming that
paper leaves at the prescribed time.
S79 LCT Relay Sensor Confirms whether the LCT is set correctly.
S80 Original Length Sensor -3 APS4 holds one original length sensor under the
exposure glass. The detection combination of
this sensor and other sensors determines the
length of the original on the exposure glass
positioned for SEF.
S81 Encoder Monitors the encoder wheel in the ITB drive
motor unit.
S82 PTR Contact Sensor Detects when the PTR is lifted or lowered.
S83 ITB Position Sensor Monitors the speed of the ITB.
Rev. 04/2008
⇒
⇒
⇒
⇒
