Specifications
D014/D015/D078/D079 7-52 SM
LEDs
LED1 Double-Feed Detection LED
Emits light which is reflected from the paper to
the double–feed detection sensor to test the
translucence of each sheet for double-feed
detection.
LED2 Accordion Jam Sensor (LED)
Flashes to show the user which lever to
release to remove a paper jam from the fusing
rollers.
LED3 Fusing Exit Sensor (LED)
Flashes to show the user which lever to
release to remove a paper jam from the fusing
unit.
SOLENOIDS
SOL1
Pick–up Solenoid:
Tray 2
Switches on when the tray 2 (middle tray) lift motor
switches on. This solenoid lowers the pick–up roller of
tray 3.
SOL2
Separation Roller
Solenoid: Tray 2
When tray 2 (middle tray) is selected as the paper
source, this solenoid energizes and brings the
separation roller in contact with the feed roller until the
leading edge of the sheet feeds to the paper feed
sensor.
SOL3
Pick–up Solenoid:
Tray 3
Switches on when the tray 3 (bottom tray) lift motor
switches on. This solenoid lowers the pick–up roller of
tray 3.
Rev. 04/2008
