SOL4
Separation Roller
Solenoid: Tray 3
When tray 3 (bottom tray) is selected as the paper
source, this solenoid energizes and brings the
separation roller in contact with the feed roller until the
leading edge of the sheet feeds to the paper feed
sensor.
SOL5
Pick–up Solenoid -
Tray 1
Switches on when the tray 1 (tandem tray) lift motor
switches on. This solenoid lowers the pick–up roller of
tray 1.
SOL6
Separation Roller
Solenoid - Tray 1
When tray 1 (tandem tray) is selected as the paper
source, this solenoid energizes and brings the
separation roller in contact with the feed roller until the
leading edge of the sheet feeds to the paper feed
sensor.
SOL7
Front Side Fence
Solenoid -Tray 1
When the right tray paper sensor in the tandem tray
signals paper out, and the left tray paper sensor signals
paper present, this energizes this solenoid which pulls
open the front side fence until the front side fence open
sensor detects the actuator of the front side fence and
switches off the solenoid, leaving it locked in the open
position, to allow the rear fence to push the paper stack
from the left tray into the right tray.
SOL8
Rear Side Fence
Solenoid - Tray 1
When the right tray paper sensor in the tandem tray
signals paper out, and the left tray paper sensor signals
paper present, this energizes this solenoid which pulls
open the rear side fence until the rear side fence open
sensor detects the actuator of the rear side fence and
switches off the solenoid, leaving it locked in the open
position, to allow rear fence to push the paper stack
from the left tray into the right tray.
