Specifications
D014/D015/D078/D079 7-54 SM
SOL9
Right Tray Lock
Solenoid - Tray 1
Releases the lock lever when the left tray paper sensor
in the tandem tray signals that there is no paper in the
left tray.
SOL10
Left Tray Lock
Solenoid - Tray 1
When the rear fence motor in the tandem tray switches
on, this energizes the left tray lock solenoid. This locks
the left tray so it does not move while the rear fence
pushes the stack from the left tray to the right tray.
SOL11
Duplex Junction
Gate Solenoid
Controls the opening and closing of the duplex junction
gate at the mouth of the inverter unit.
SOL12
Reverse Trigger
Roller Solenoid
After a sheet is detected by the duplex entrance sensor,
this solenoid energizes and pushes down the reverse
trigger roller.
SOL13
Guide Plate
Solenoid
Energizes when a jam occurs between the vertical
transport rollers and registration roller to force the guide
plate open and divert paper fed from below into the
duplex tray.
SOL14
Inverter Junction
Gate Solenoid
Operates the inverter junction gate. The inverter
injunction gate turns paper into the path to the inverter
unit below where it is 1) inverted for face–down output or
2) inverted for 2nd side printing.
SOL15
Bypass Pick–up
Solenoid
Switches on and lowers the pick–up roller to the top of
the stack in the bypass tray
SOL16 Charge Cleaning
Solenoid: Y
Raises and lowers the Y charge roller cleaning roller.
SOL17 Charge Cleaning
Solenoid: C
Raises and lowers the C charge roller cleaning roller.
SOL18 Charge Cleaning
Solenoid: M
Raises and lowers the M charge roller cleaning roller.
SOL19 Duplex Inverter
Solenoid
Operates the duplex inverter junction gate.
