Specifications
SM 7-57 D014/D015/D078/D079
Specifications
ARDF
No. Component Function
MOTORS
M1 Feed Motor
Drives the feed belt, and the separation, pick-up, and
transport as far as the 1st transport roller.
M2 Transport Motor Controls the original scanning speed.
M3 Exit Motor
Feeds paper out of the ARDF and onto the original exit
table.
M4 Upper Inverter Motor
Controls the rotation of the upper inverter roller that
feeds the original in and out of the upper inverter path.
M5 Lower Inverter Motor
Controls the rotation of the lower inverter roller that
feeds the original in and out of the lower inverter path.
M6 Pick-up Motor Raises and lowers the pick-up roller.
M7
Bottom Plate Lift
Motor
Raises and lowers the bottom under the original stack.
PCB
PCB1 ARDF Main Board
Controls the ARDF and communicates with the main
copier boards.
Rev. 04/2008
