Specifications
D014/D015/D078/D079 7-58 SM
SENSORS
S1
Original Width Sensor
2
Detects paper wider than 191.5 mm (7.5 in.) measured
from the reference point.
S2
Original Width Sensor
3
Detects paper wider than 230 mm (9.1 in.) measured
from the reference point.
S3
Original Width Sensor
4
Detects paper wider than 263.5 mm (10.4 in.)
measured from the reference point.
S4
Original Width Sensor
5
Detects paper wider than 288 mm (11.3 in.) measured
from the reference point.
S5
Original Width Sensor
1
Detects paper wider than 138 mm (5.4 in.) measured
from the reference point.
S6 Original Set Sensor Detects whether an original is on the table.
S7
Bottom Plate HP
Sensor
Detects whether the bottom plate is in the down
position or not.
S8 Feed Cover Sensor Detects whether the feed cover is open or not.
S9
Bottom Plate Position
Sensor
Detects when the original is at the correct position for
feeding.
S10 Upper Inverter Sensor
Detects leading and trailing edge of the paper as it
enters and leaves the upper path of the inverter.
S11 LG Detection Sensor
Detects paper longer than 318 mm (12.5 in.) on the
original table.
S12 A4 Detection Sensor
Detects paper longer than 291 mm (11.5 in.) on the
original table.
S13 B5 Detection Sensor
Detects paper longer than 240 mm (9.5 in.) on the
original table.
Rev. 04/2008
