Specifications
SM 7-59 D014/D015/D078/D079
Specifications
S14 Interval Sensor
Adjusts the timing of the original transport speed to the
original scanning speed after the original feeds. During
duplex scanning, or if original is small (B6, A5, or HLT)
the interval sensor detects the leading edge of the
original and delays the pre-scanning motor for the
prescribed number of pulses to buckle the original and
correct skew.
S15
Skew Correction
Sensor
After pick-up and separation, the skew correction
sensor detects the leading edge of the original. This
signal slows the rotation of the entrance roller for a
prescribed number of pulses to buckle the original and
correct skew.
S16 Separation Sensor Detects the separation of the original.
S17 Exit Sensor
Detects the leading and trailing edges of paper feed
out to the original table and detects misfeeds. Also
signals when to stop the scanning belt.
S18 Registration Sensor
Detects the leading edge and trailing edges of the
original to detects jams and stops the original at the
ADF exposure glass to correct buckle.
S19
Pick-up Roller HP
Sensor
Detects whether the pick-up roller is up or not.
S20 Lower inverter sensor
Detects the original in the path of the lower inverter
before it feeds to the inverter rollers for 2nd side
scanning, or feeds to the exit rollers for exit.
S21 ARDF Position Sensor
Detects whether the ARDF unit is up or down for
scanning on the main exposure glass (book mode).
S22 APS Start Sensor
Signals the CPU when the DF is opened and closed
(for platen mode) so that the original size sensors in
the copier can check the original size.
Rev. 04/2008
