Specifications
D014/D015/D078/D079 7-60 SM
SOLENOIDS
SOL1
Upper Inverter
Solenoid
Opens and closes the upper junction gate at the
entrance of the upper inverter path. During simplex
scanning, closes the upper inverter path so the
original exits straight to the exit tray. During duplex
scanning, opens to allow the original to enter the
upper inverter path and closes to direct it once again
into the feed path for 2nd side scanning.
SOL2
Lower Inverter
Solenoid
Opens and closes the lower junction gate. During
duplex scanning opens after the 2nd side is scanned
to direct the original into the lower inverter path while
the next sheet is fed to the upper inverter path above,
then closes to direct the original out onto the original
exit tray.
Rev. 04/2008
