OVERALL MACHINE INFORMATION
B830 68 SM
1. Exit Guide HP Sensor
2. Exit Guide Motor
3. Upper Tray Full Sensor
4. Upper Tray Exit Sensor
5. Stapler Tray Entrance Sensor
6. Entrance Sensor
7. Punch-Out Hopper Full Sensor
8. Pre-Stack Tray Paper Sensor (Left)
9. Staple Trimmings Hopper Set Sensor
10. Staple Trimmings Hopper Full Sensor
11. Stapler Tray Exit Sensor
12. Pre-Stack Tray Paper Sensor (Right)
13. Front Door Safety Switch
14. Shift Tray Exit Sensor 2
15. Shift Tray Exit Sensor 1
B830V502E.WMF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
