Ricoh D014 - Page 1406

Installation
SM 5 D356
D356
Fax Option
Type C7500
12. Reattach:
 Controller box [A] (x16)
 Rear lower cover (x2)
 Rear upper cover (x3, Stepped x2)
1. Connect the telephone cable to the "LINE 1" jack.
2. Attach the ferrite core to the telephone cable.
 The end of the ferrite core must be about 5 cm (2.1") from the end of the
cable.
