Ricoh D014 - Page 1421

Error Codes
D356 20 SM
Code Meaning Suggested Cause/Action
0-21
EOL signal (end-of-line)
from the other end not
received within 5 s of the
previous EOL signal
 Check the connections between the FCU,
NCU, & line.
 Check for line noise or other line
problems.
 Replace the NCU or FCU.
 The remote machine may be defective or
may have disconnected.
Cross reference
 Maximum interval between EOLs and
between ECM frames - G3 Bit Switch 0A,
bit 4
0-22
The signal from the other
end was interrupted for
more than the acceptable
modem carrier drop time
(default: 200 ms)
 Check the line connection.
 Check the FCU - NCU connectors.
 Replace the NCU or FCU.
 Defective remote terminal.
 Check for line noise or other line
problems.
 Try adjusting the acceptable modem
carrier drop time.
Cross reference
 Acceptable modem carrier drop time - G3
Switch 0A, bits 0 and 1
