Ricoh D014 - Page 465

Service Call Tables
SM 4-15 D014/D015/D078/D079
Trouble-
shooting
SC240 C LD error: K
SC241 C LD error: Y
SC242 C LD error: M
SC243 C LD error: C
An error occurred at the LD
error terminal of the K, Y, M, or
C LD driver after initialization
of the LD because the power
to the LD was higher or lower
than the prescribed limit.
 LD defective due to wear, damage,
short circuit
 LDB harness disconnected, loose or
defective
Optical unit sensor error
SC268 C
At power on, one of the two
temperature sensors in the
optics unit detected a
temperature lower than -10°C.
-or-
It detected a temperature
higher than 80°C.
 Thermistor disconnected (causes
extremely low temperature reading)
 Thermistor damaged and short
circuited (causes extremely high
temperature reading)
 VBCU defective
Skew Control Upper Lower Limit: Y
SC270 C
The pulse total for Yellow skew
control is not within the
prescribed range.
 ITB not installed correctly.
 ITB defective
 Optical unit installed incorrectly
 Optical unit defective
