Service Call Tables
D014/D015/D078/D079 4-16 SM
Skew Control Upper Lower Limit: M
SC271 C
The pulse total for Magenta
skew control is not within the
prescribed range.
 ITB not installed correctly.
 ITB defective
 Optical unit installed incorrectly
 Optical unit defective
Skew Control Upper Lower Limit: C
SC272 C
The pulse total for Cyan skew
control is not within the
prescribed range.
 ITB not installed correctly.
 ITB defective
 Optical unit installed incorrectly
 Optical unit defective
MUSIC Continuous Failure
SC285 C
The MUSIC adjustment failed
after four attempts.
 Fusing belt installed incorrectly
 Fusing belt surface scoured,
scratched
 MUSIC sensors dirty, defective
