Service Call Tables
D014/D015/D078/D079 4-38 SM
Duplex Jogger Motor Error 2
SC516
B
When the jogger fence moves
from the home position, the
jogger fence HP sensor does
not turn off even if the jogger
motor has moved the jogger
fence 153.5 mm.
 Jogger fence motor defective or
poor connection
 Paper or other obstacle interfering
with operation of the sensors or
motor
 Return sensor or HP sensor
defective, dirty, or disconnected
 Paper or other obstacle has jammed
mechanism
 HP sensor connector disconnected
or defective
 HP sensor defective
LCIT Air Assist Front Fan Error
SC517 D
The front air assist fan is not
functioning properly.
 Fan harness disconnected or
damaged
 Fan blocked by an obstruction
 Fan damaged, defective
LCIT Air Assist Rear Fan Error
SC518 D
The rear air assist fan is not
functioning properly.
 Fan harness disconnected or
damaged
 Fan blocked by an obstruction
 Fan damaged, defective
Rev. 09/2008
