Service Call Tables
D014/D015/D078/D079 4-60 SM
Booklet stapler motor error 2
SC744 B
The rear stapler unit saddle-stitch
motor does not start operation within
the specified time. The 1st detection
failure causes a jam error, and the 2nd
failure causes this SC code.
 Rear motor disconnected,
defective
 Rear motor overloaded due
to obstruction
Feed-Out Belt Motor Error (D373/B830)
SC745 D
The stack feed-out belt HP sensor does not activate within the specified
time after the stack feed-out belt motor turns on. The 1st detection failure
causes a jam error, and the 2nd failure causes this SC code.
If the motor is operating
1. Stack feed-out HP sensor harness loose, broken, defective
2. Stack feed-out HP sensor defective
If the motor is not operating:
1. Feed-out motor blocked by an obstruction
2. Feed-out motor harness loose, broken, defective
3. Feed-out motor defective
4. Booklet finisher main board defective
Stack Plate Motor Error 1: Front Motor (B830)
SC746 D
The stack plate HP sensor (front) does not activate within 500 ms after
the motor turns on. The 1st detection failure causes a jam error, and the
2nd failure causes this SC code.
If the motor is operating
1. Front stack plate HP sensor harness loose, broken, defective
2. Front stack plate HP sensor defective
If the motor is not operating:
1. Motor blocked by an obstruction
2. Motor harness loose, broken, defective
3. Motor defective
4. Booklet finisher main board defective
